Measuring Platform

We provide a wide range of products that all are associated with ship dynamics. Many simply refer to these as “The SAJ”.

Dynamic sensors

The SAJ-DMS system measuring platform comprises one to three dynamic sensors. The number of sensors depends on the type and the length of the ship. Our dynamic sensors are measuring the ship’s trim and and the ship’s heel at the sensor locations. These sensors are measuring in unison with the only though-hull draft transducer.

All information from these sensors are processed and analysed continuously in the SAJ-DMS system. This provides real-time information about Dynamic Trim, List, Torsion, Deflection and Draft as well as Displacement. The difference between an inclinometer based system and a dynamic sensor based system such as the SAJ-DMS system, is the accuracy. Additionally the dynamic sensors are not affected by G-forces, temperature changes or speed through water. Thanks to the Dynamic sensor we can measure large ship’s dynamics accurately 24/7.

Client and server

The system is built with client/server technology and is running on a tailor made PC on the bridge. All information is presented in an easy to use graphical user interface on a monitor. The user interface is optimised for use with a touch screen.

Remote presentation

Remote presentation is possible at any location in the ship by using of optional workstation clients. There are aslo options for interfaces to share signals with other third party systems. A number of interface standards are available from NMEA to analogue signals. Also a communication kit is available that allows remote access for performing updates and other maintenance activities.

The system can be further enhanced by add-on software modules the offer more opportunities go get advantages from the real-time dynamic sensor information.

Contact us

Please contact us, we can provide more details how our products could benefit you in your operation or your particular projects.
